3104 Aluminum sheet belongs to the Al-Mn series of wrought aluminum alloys and is a typical representative of the 3000 series rust-proof aluminum.
3104 Aluminum sheet belongs to the Al-Mn series of wrought aluminum alloys and is a typical representative of the 3000 series rust-proof aluminum. Its tensile strength is ≥275 MPa, with an elongation rate of up to 20%, combining high strength with excellent plasticity. This material cannot be strengthened by heat treatment but can enhance mechanical properties through cold working, making it widely used in deep-drawing applications. Key features include:
Excellent corrosion resistance, weldability, and deep-drawing performance
Stable surface quality, high dimensional accuracy, and superior metallurgical quality
Compliance with food-grade safety standards
|
Alloy |
3104 aluminum sheet |
|
Temper |
F,O,H12,H14,H16,H18,H19,H22,H24,H26,H28,H112,H114,etc. |
|
Thickness |
1.0-500 |
|
Width |
100-2650 |
|
Length |
500-16000 |
|
Application |
Canned material, oxidized material, canned beer, canned cola, etc. |
|
Alloy |
Si |
Fe |
Cu |
Mn |
Mg |
Zn |
Cr |
Others |
Al |
|
|
3104 |
0.60 |
0.70 |
0.05-0.20 |
1.00-1.50 |
- |
0.10 |
- |
Single |
Total |
Remain |
|
0.05 |
0.15 |
|||||||||
20% elongation, suitable for complex forming processes, reducing material waste.
Manganese content forms a dense oxide film, ideal for harsh environments like humidity and salt spray.
Supports cold working, welding, and stamping, meeting high-precision production demands.
Low density (2.73 g/cm³), reducing transportation and usage costs.
Non-toxic and non-reactive with food, complying with international hygiene standards.
More affordable than 5000-series aluminum alloys, with broad market applications.
"Our company has been using 3104 aluminum sheets for can production for years—this material is truly reliable and worry-free! Its deep-drawing performance is outstanding, significantly reducing defect rates. Moreover, the corrosion resistance of 3104 aluminum is exceptional. Whether for product quality or cost control, 3104 aluminum is our top choice!"
